RED WEAPON MONSTRO 8K VV

FULL FRAME Sensor
Vastly improved noise performance
Dynamic Range: 17.5+ Stops
35.4 Megapixels for Film, Photo and Print Campaignsn
High Speed: Up to 100 fps in 6K, 120 fps in 5K and 300 fps in 2K
RAW Recording 16-bit
ProRes, DNxHD Recording 4K & 2K
RAW & ProRes, DNxHD Recording Simultaneously
3D LUT, 1D LUT
Interchangeable OLPF

Extended possibilities for reframing, VFX, motion stabilization
Automatic Sensor Calibration (Black Shading)
New Cooling System (Quieter Camera)
Two LCD/EVF Outputs
Built-in Microphones
IPP2: New Color Science
Natural Color Reproduction, Especially for Skin Tones
Extended Highlights, Soft Roll-off
Correction of Over/Underexposure
Extremely Low-noise

Formate & FPS: RED WEAPON MONSTRO 8K VV

Format	Aspect Ratio	Resolution	FPS (MONSTRO 8K VV)	Dimensions (mm)
ANAMORPHIC	RED WEAPON cameras support ANAMORPHIC 1.3x and 2x with each format. The camera offers a 6:5 aspect ratio for each resolution. Using a 6:5 aspect ratio at 2x anamorphic gives you a 2.40:1 aspect ratio.
8K FF	1.90 : 1	8192 x 4320	1 - 61	40.96 x 21.60 - ∅ 46.31
8K 2:1	2 : 1	8192 x 4096	1 - 64	40.96 x 20.48 - ∅ 45.79
8K WS	2.37 : 1	8192 x 3456	1 - 76	40.96 x 17.28 - ∅ 44.46
8K HD	1.78 : 1	7680 x 4320	1 - 61	38.40 x 21.60 - ∅ 44.06
8K 14:9	1.56 : 1	6720 x 4320	1 - 61	33.60 X 21.60 - ∅ 39.94
8K 3:2	1.50 : 1	6480 x 4320	1 - 61	32.40 x 21.60- ∅ 38.94
8K 6:5	1.20 : 1	5184 x 4320	1 - 61	25.92 x 21.60 - ∅ 33.74
8K 4:1	4 : 1	8192 x 2048	1 - 127	40.96 x 10.24 - ∅ 42.22
8K 8:1	8 : 1	8192 x 1024	1 - 251	40.96 x 4.12 - ∅ 41.28
7.5K FF	1.88 : 1	7680 x 4080	1 - 64	38.40 x 20.40 - ∅ 43.48
7.5K 2:1	2 : 1	7680 x 3840	1 - 68	38.40 x 19.20 - ∅ 42.93
7.5K WS	2.37 : 1	7680 x 3240	1 - 81	38.40 x 16.20 - ∅ 41.68
7.5K HD	1.78 : 1	7296 x 4104	1 - 64	36.48 x 20.52 - ∅ 41.86
7.5K 4:1	4 : 1	7680 x 1920	1 - 135	38.40 x 9.60 - ∅ 39.58
7.5K 8:1	8 : 1	7680 x 960	1 - 267	238.40 x 4.80- ∅ 38.70
7K FF	1.90 : 1	7168 x 3780	1 - 69	35.84 x 18.90 - ∅ 40.52
7K 2:1	2 : 1	7168 x 3584	1 - 73	35.84 x 1792 - ∅ 40.07
7K WS	2.37 : 1	7168 x 3024	1 - 86	35.84 x 15.12 - ∅ 38.90
7K HD	1.78 : 1	6720 x 3780	1 - 69	33.60 x 19.90 - ∅ 38.55
7K 6:5	1.20 : 1	4536 x 3780	1 - 69	22.68 x 18.90- ∅ 29.52
7K 4:1	4 : 1	7168 x 1792	1 - 144	35.84 x 8.96- ∅ 36.94
7K 8:1	8 : 1	7168 x 896	1 - 282	35.84 x 4.48 - ∅ 36.12
6.5K FF	1.88 : 1	6656 x 3536	1 - 74	33.28 x 17.68 - ∅ 37.68
6.5K 2:1	2 : 1	6656 x 3328	1 - 78	33.28 x 16.64 - ∅ 37.21
6.5K WS	2.37 : 1	6656 x 2808	1 - 93	33.28 x 14.04 - ∅ 36.12
6.5K HD	1.78 : 1	6144 x 3456	1 - 76	30.72 x 17.28 - ∅ 35.25
6.5K 4:1	4 : 1	6656 x 1664	1 - 156	33.28 x 8.32 - ∅ 34.30
6.5K 8:1	8 : 1	6656 x 832	1 - 307	33.28 x 4.16 - ∅ 33.54
6K FF	1.90 : 1	6144 x 3240	1 - 81	30.72 x 16.20 - ∅ 34.73
6K 2:1	2 : 1	6144 x 3072	1 - 85	30.72 x 15.36 - ∅ 34.35
6K WS	2.37 : 1	6144 x 2592	1 - 101	30.72 x 12.96 - ∅ 33.34
6K HD	1.78 : 1	5760 x 3240	1 - 81	28.80 x 16.20 - ∅ 33.04
6K 3:2	1.50 : 1	5760 x 3840	1 - 68	28.80 x 19.20 - ∅ 34.61
6K 4:3	1.33 : 1	5760 x 4320	1 - 61	28.80 x 21.60 - ∅ 36.00
6K 6:5	1.20 : 1	3888 x 3240	1 - 81	19.44 x 16.20 - ∅ 25.31
6K 4:1	4 : 1	6144 x 1536	1 - 169	30.72 x 7.68 - ∅ 31.67
6K 8:1	8 : 1	6144 x 768	1 - 333	30.72 x 3.84 - ∅ 30.96
5.5K FF	1.91 : 1	5632 x 2948	1 - 89	28.16 x 14.74 - ∅ 31.78
5.5K 2:1	2 : 1	5632 x 2816	1 - 93	28.16x 14.08 - ∅ 31.48
5.5K WS	2.37 : 1	5632 x 2376	1 - 110	28.16 x 11.88 - ∅ 30.56
5.5K HD	1.78: 1	5376 x 3024	1 - 87	26.88 x 15.12 - ∅ 30.84
5.5K 4:1	4 : 1	5632 x 1408	1 - 185	28.16 x 7.04 - ∅ 29.03
5.5K 8:1	8 : 1	5632 x 704	1 - 364	28.16 x 3.52 - ∅ 28.38
5K FF	1.90 : 1	5120 x 2700	1 - 96	25.60 x 13.50 - ∅ 28.94
5K 2:1	2 : 1	5120 x 2560	1 - 102	25.60 x 12.80 - ∅ 28.62
5K WS	2.37 : 1	5120 x 2160	1 - 120	25.60 x 10.80 - ∅ 27.78
5K HD	1.78 : 1	4800 x 2700	1 - 96	24.00 x 13.50 - ∅ 27.54
5K 6:5	1.20 : 1	3240 x 2700	1 - 96	16.20 x 13.50 - ∅ 21.09
5K 4:1	4 : 1	5120 x 1280	1 - 200	25.60 x 6.40 - ∅ 26.39
5K 8:1	8 : 1	5120 x 640	1 - 390	25.60 x 3.20 - ∅ 25.80
4.5K FF	1.91 : 1	4608 x 2412	1 - 108	23.04 x 12.06 - ∅ 26.01
4.5K 2:1	2 : 1	4608 x 2304	1 - 113	23.04 x 11.52 - ∅ 25.76
4.5K WS	2.37 : 1	4608 x 1944	1 - 134	23.04 x 9.72 - ∅ 25.01
4.5K HD	1.82 : 1	4320 x 2376	1 - 110	21.60 x11.88 - ∅ 24.65
4.5K 3:2	1.50 : 1	4320 x 2880	1 - 91	21.60 x 14.40 - ∅ 25.96
4.5K 4:3	1.33 : 1	4320 x 3240	1 - 81	21.60 x 16.20 - ∅ 27.00
4.5K 5:4	1.25 : 1	47320 x 3456	1 - 76	21.60 x 17.28 - ∅ 27.66
4.5K 4:1	4 : 1	4608 x 1152	1 - 225	23.04 x 5.76 - ∅ 23.75
4.5K 8:1	8 : 1	4608 x 576	1 - 400	23.04 x 2.88 - ∅ 23.22
4K FF	1.90 : 1	4096 x 2160	1 - 121	20.48 x 10.80 - ∅ 23.15
4K 2:1	2 : 1	4096 x 2048	1 - 127	20.48 x 10.24 - ∅ 22.90
4K WS	2.37 : 1	4096 x 1728	1 - 151	20.48 x 8.64 - ∅ 22.23
4K HD	1.78 : 1	3840 x 2160	1 - 121	19.20 x 10.80- ∅ 22.03
4K 3:2	1.50 : 1	3840 x 2560	1 - 102	19.20 x 12.80 - ∅ 23.08
4K 4:3	1.33 : 1	3840 x 2880	1 - 91	19.20 x 14.40 - ∅ 24.00
4K 5:4	1.25 : 1	3840 x 3072	1 - 85	19.20 x 15.36 - ∅ 24.59
4K 6:5	1.20 : 1	2592 x 2160	1 - 121	12.96 x 10.80 - ∅ 16.87
4K 4:1	4 : 1	4096 x 1024	1 - 253	20.48 x 5.12 - ∅ 21.11
4K 8:1	8 : 1	4096 x 512	1 - 400	20.48 x 2.56 - ∅ 20.64
4K 1:1	1 : 1	4320 x 4320	1 - 30	21.60 x 21.60 - ∅ 30.55
3.5K FF	1.91 : 1	3584 x 1876	1 - 139	17.92 x 9.38 - ∅ 20.23
3.5K 2:1	2 : 1	3854 x 1792	1 - 145	17.92 x 8.96 - ∅ 20.04
3.5K WS	2.37 : 1	3584 x 1512	1 - 172	17.92 x 7.56 - ∅ 19.45
3.5K HD	1.78 : 1	3456 x 1944	1 - 134	17.28 x 9.72 - ∅ 19.83
3.5K 3:2	1.50 : 1	3360 x 2240	1 - 117	16.80 x 11.20 - ∅ 20.19
3.5K 4:3	1.33 : 1	3360 x 2520	1 - 104	16.80 x 12.60 - ∅ 21.00
3.5K 5:4	1.25 : 1	3360 x 2688	1 - 97	16.80 x 13.44 - ∅ 21.51
3.5K 4:1	4 : 1	3584 x 896	1 - 288	17.92 x 4.48 - ∅ 18.47
3.5K 8:1	8 : 1	3584 x 448	1 - 400	17.92 x 2.24 - ∅ 18.06
3K FF	1.90 : 1	3072 x 1620	1 - 160	15.36 x 8.10 - ∅ 17.36
3K 2:1	2 : 1	3072 x 1536	1 - 169	15.36 x 7.68 - ∅ 17.17
3K WS	2.37 : 1	3072 x 1296	1 - 200	15.36 x 6.48 - ∅ 16.67
3K HD	1.78 : 1	2880 x 1620	1 - 160	14.40 x 8.10 - ∅ 16.52
3K 3:2	1.50 : 1	2880 x 1920	1 - 136	10.51 x 7.01 - ∅ 12.63
3K 4:3	1.33 : 1	2880 x 2160	1 - 121	14.40 x 10.80 - ∅ 18.00
3K 5:4	1.25 : 1	2880 x 2304	1 - 113	14.40 x 11.52 - ∅ 18.44
3K 6:5	1.20 : 1	1944 x 1620	1 - 160	9.72 x 8.10 - ∅ 12.65
3K 4:1	4 : 1	3072 x 768	1 - 333	15.36 x 3.84 - ∅ 15.83
3K 8:1	8 : 1	3072 x 384	1 - 400	15.36 x 1.92 - ∅ 15.48
2.5K FF	1.91 : 1	2560 x 1340	1 - 192	12.80 x 6.70 - ∅ 14.45
2.5K 2:1	2 : 1	2560 x 1280	1 - 201	12.80 x 6.40 - ∅ 14.31
2.5K WS	2.37 : 1	2560 x 1080	1 - 237	12.80 x 5.40 - ∅ 13.89
2.5K HD	1.78 : 1	2304 x 1296	1 - 194	11.52 x 6.48 - ∅ 13.22
2.5K 3:2	1.50 : 1	2400 x 1600	1 - 161	12.00 x 8.00 - ∅ 14.42
2.5K 4:3	1.33 : 1	2400 x 1800	1 - 144	12.00 x 9.00 - ∅ 15.00
2.5K 5:4	1.25 : 1	2400 x 1920	1 - 135	12.00 x 9.60 - ∅ 15.37
2.5K 4:1	4 : 1	2560 x 640	1 - 393	12.80 x 3.20 - ∅ 13.19
2.5K 8:1	8 : 1	2560 x 320	1 - 400	12.80 x 1.60 - ∅ 12.90
2K FF	1.90 : 1	2048 x 1080	1 - 241	10.24 x 5.40 - ∅ 11.58
2K 2:1	2 : 1	2048 x 1024	1 - 253	10.24 x 5.12 - ∅ 11.45
2K WS	2.37 : 1	2048 x 864	1 - 301	10.24 x 4.32- ∅ 11.11
2K HD	1.78 : 1	1920 x 1080	1 - 241	9.60 x 5.40 - ∅ 11.01
2K 3:2	1.50 : 1	1920 x 1280	1 - 203	9.60 x 6.40 - ∅ 11.54
2K 4:3	1.33 : 1	1920 x 1440	1 - 180	9.60 x 7.20 - ∅ 12.00
2K 5:4	1.25 : 1	1920 x 1536	1 - 169	9.60 x 7.68 - ∅ 12.29
2K 6:5	1.20 : 1	1296 x 1080	1 - 240	6.48 x 5.40 - ∅ 8.44
2K 4:1	4 : 1	2048 x 512	1 - 400	10.24 x 2.56 - ∅ 10.56
2K 8:1	8 : 1	2048 x 256	1 - 400	10.24 x 1.28 - ∅ 10.32

Technische Spezifikationen

	RED Weapon 8K VV MONSTRO
Sensor	35.4 Megapixel CMOS MONSTRO™
Pixel Array	8192 (h) x 4320 (v)
S/N Ratio	80db
Dynamic Range	17.5+ stops
Sensitivity	ISO 400 - 1600 Base Range ISO 250 - 12800 (Metadata)
Lens Coverage	40.96mm (h) x 21.60mm (v) x 46.31mm (d)
Lens Mounts	PL Canon EF/EF-S
Film Format	VV+ FF S35+ S35 A35 S16
Acquisition Formats	ANAMORPHIC 1.3x and 2x with each format 8K RAW FF 7.5K RAW FF 7K RAW FF 6.5K RAW FF 6K RAW FF 5.5K RAW FF 5K RAW FF 4.5K RAW FF 4K RAW FF 3.5K RAW FF 3K RAW FF 2.5K RAW FF 2K RAW FF 4K Apple ProRes 422 HQ, up to 29.97 fps 4K Apple ProRes 422, up to 29.97 fps 4K Apple ProRes 422 LT, up to 29.97 fps 2K Apple ProRes 4444 XQ, up to 120 fps 2K Apple ProRes 4444, up to 120 fps 2K Apple ProRes 422 HQ, up to 120 fps 2K Apple ProRes 422, up to 120 fps 2K Apple ProRes 422 LT, up to 120 fps 4K DNxHR HQX, up to 29.97 fps 4K DNxHR HQ, up to 29.97 fps 4K DNxHR SQ, up to 29.97 fps 4K DNxHR LB, up to 29.97 fps DNxHR 444, up to 120 fps DNxHD 444, up to 120 fps DNxHD HQX, up to 120 fps DNxHD HQ, up to 120 fps DNxHD SQ, up to 120 fps DNxHD LB, up to 120 fps
Project Frame Rates	23.98, 24, 25, 29.97,47.95, 48, 50, 59.94, all resolutions
Recording	REDCODE RAW + QuickTime ProRes simultanous REDCODE RAW + Avid Codecs simulanous REDCODE RAW only QuickTime ProRes only Avid Codec only
Max Data Rates	300 MB/s using RED MINI-MAG® (512GB & 1TB) 225 MB/s using RED MINI-MAG (120GB & 240GB)
Max Frame Rates	60 fps at 8K FF and 12:1 REDCODE 75 fps at 8K 2.4:1 and 12:1 REDCODE 60 fps at 7K FF and 10:1 REDCODE 75 fps at 7K 2.4:1 and 10:1 REDCODE 75 fps at 6K FF and 9:1 REDCODE 100 fps at 6K 2.4:1 and 9:1 REDCODE 96 fps at 5K FF and 8:1 REDCODE 120 fps at 5K 2.4:1 and 8:1 REDCODE 100 fps at 4.5K FF and 7:1 REDCODE 120 fps at 4.5K 2.4:1 and 7:1 REDCODE 120 fps at 4K FF and 6:1 REDCODE 150 fps at 4K 2.4:1 and 7:1 REDCODE 150 fps at 3K FF and 5:1 REDCODE 200 fps at 3K 2.4:1 and 5:1 REDCODE 240 fps at 2K FF and 4:1 REDCODE 300 fps at 2K 2.4:1 and 4:1 REDCODE
REDCODE Settings Range from 2:1 up to 22:1	5:1 REDCODE for 8K Full Frame (8192 x 4320) at 24 fps 12:1 REDCODE for 8K Full Frame (8192 x 4320) at 60 fps 2:1 REDCODE for 4K Full Frame (4096 x 2160) at 24 fps 3:1 REDCODE for 4K Full Frame (4096 x 2160) at 60 fps
Delivery Formats	4K: DPX, TIFF, OpenEXR (RED via RRencode plugin) 2K : DPX, TIFF, OpenEXR (RED via RRencode plugin) 1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4
Program Output	HD-SDI Clean Feed 2K RGB, 1080p RGB or 4:2:2 720p 4:2:2 SMPTE Timecode, HANC Metadata 24-bit 48Khz Audio
Monitor Output	3G-SDI (HD-SDI) and HDMI® with DSMC² expander module 1080p RGB or 4:2:2, 720p RGB or 4:2:2 480p RGB or 4:2:2 (HDMI Only) SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio
Digital Media	RED MINI-MAG SSD: 512GB & 1TB, 300 MB/s RED MINI-MAG SSD: 120GB & 240GB, 225 MB/s
Monitoring Options	DSMC RED Touch 7.0" Touch LCD DSMC RED Touch 4.7" Touch LCD DSMC RED EVF(OLED) RED Pro 7" LCD" RED Touch 5", 7", 9" LCD BOMB EVF (LCOS) High Definition Viewfinder BOMB EVF (OLED) High Definition Viewfinder
Color Management	Supports 33×33×33, 32×32×32, 26×26×26, and 17×17×17 3D LUTs Variable number of 3D LUT outputs with DSMC²™ expander module User programmable shaper 1D LUTs Tetrahedral interpolation, 16-bit process
Audio	Integrated dual channel digital stereo microphones, uncompressed, 24-bit 48 kHz Optional 2 channels with DSMC² expander module, umcompressed 24-bit, 48KHz
Remote Control	Integrated REDLINK® WiFi Ethernet, RS232, GPI Trigger	>
Weight	3.3lbs. (BRAIN® with Integrated Media Bay)
Construction	Carbon Fiber, Magnesium, Aluminum Alloy

RED HELIUM 8K S35 Sensor

RED WEAPON & EPIC-W

8K S35 HELIUM Sensor
Vastly improved noise performance
Dynamic Range: 16.5+ Stops
35.4 Megapixels for Film, Photo and Print Campaigns
High Speed: Up to 100 fps in 6K, 120 fps in 5K and 300 fps in 2K
RAW Recording 16-bit
ProRes, DNxHD Recording 4K & 2K
RAW & ProRes, DNxHD Recording Simultaneously
3D LUT, 1D LUT
Interchangeable OLPF
Extended possibilities for reframing, VFX, motion stabilization

Automatic Sensor Calibration (Black Shading)
New Cooling System (Quieter Camera)
Two LCD/EVF Outputs
Built-in Microphones
New Color Science
Natural Color Reproduction, Especially for Skin Tones
Extended Highlights, Soft Roll-off
Correction of Over/Underexposure
Extremely Low-noise
Integrated 8x Electronic ND Filter (with RED Motion Mount)
Global Shutter (with RED Motion Mount)

Formats & FPS: RED WEAPON & EPIC-W 8K

Format	Aspect Ratio	Resoultion	FPS (WEAPON/EPIC-W)	Dimensions (mm)
ANAMORPHIC
8K FF	1.90 : 1	8192 x 4320	1 - 61 / 30	29.90 x 15.77 - ∅ 33.80
8K 2:1	2 : 1	8192 x 4096	1 - 64 / 32	29.90 x 14.95 - ∅ 33.43
8K WS	2.37 : 1	8192 x 3456	1 - 76 / 38	29.90 x 12.61 - ∅ 32.45
8K HD	1.78 : 1	7680 x 4320	1 - 61 / 30	28.03 x 15.77 - ∅ 32.16
8K 14:9	1.56 : 1	6720 x 4320	1 - 61 / 30	24.53 x 15.77 - ∅ 29.16
8K 3:2	1.50 : 1	6480 x 4320	1 - 61 / 30	23.65 x 15.77- ∅ 28.43
8K 6:5	1.20 : 1	5184 x 4320	1 - 61 / 30	18.92 x 15.77 - ∅ 24.63
8K 4:1	4 : 1	8192 x 2048	1 - 127 / 64	29.90 x 7.48 - ∅ 30.82
8K 8:1	8 : 1	8192 x 1024	1 - 251 / 129	29.90 x 3.74 - ∅ 30.13
7.5K FF	1.88 : 1	7680 x 4080	1 - 64 / 32	28.03 x 14.89 - ∅ 31.74
7.5K 2:1	2 : 1	7680 x 3840	1 - 68 / 34	28.03 x 14.02 - ∅ 31.34
7.5K WS	2.37 : 1	7680 x 3240	1 - 81 / 41	28.03 x 11.83 - ∅ 30.42
7.5K HD	1.78 : 1	7296 x 4104	1 - 64 / 32	26.63 x 14.98 - ∅ 30.55
7.5K 4:1	4 : 1	7680 x 1920	1 - 135 / 69	28.03 x 7.01 - ∅ 28.89
7.5K 8:1	8 : 1	7680 x 960	1 - 267 / 137	28.03 x 3.50 - ∅ 28.25
7K FF	1.90 : 1	7168 x 3780	1 - 69 / 35	26.16 x 13.80 - ∅ 29.58
7K 2:1	2 : 1	7168 x 3584	1 - 73 / 37	26.16 x 13.08 - ∅ 29.25
7K WS	2.37 : 1	7168 x 3024	1 - 86 / 44	26.16 x 11.04 - ∅ 28.39
7K HD	1.78 : 1	6720 x 3780	1 - 69 / 35	24.53 x 13.80 - ∅ 28.15
7K 6:5	1.20 : 1	4536 x 3780	1 - 69 / 35	16.56 x 13.80 - ∅ 21.56
7K 4:1	4 : 1	7168 x 1792	1 - 144 / 73	26.16 x 6.54 - ∅ 26.97
7K 8:1	8 : 1	7168 x 896	1 - 282 / 147	26.16 x 3.27 - ∅ 26.36
6.5K FF	1.88 : 1	6656 x 3536	1 - 74 / 37	24.29 x 12.91 - ∅ 27.51
6.5K 2:1	2 : 1	6656 x 3328	1 - 78 / 40	24.29 x 12.15 - ∅ 27.16
6.5K WS	2.37 : 1	6656 x 2808	1 - 93 / 47	24.29 x 10.25 - ∅ 26.36
6.5K HD	1.78 : 1	6144 x 3456	1 - 76 / 38	22.43 x 12.61 - ∅ 25.73
6.5K 4:1	4 : 1	6656 x 1664	1 - 156 / 79	24.29 x 6.07 - ∅ 25.04
6.5K 8:1	8 : 1	6656 x 832	1 - 307 / 158	24.29 x 3.04 - ∅ 24.48
6K FF	1.90 : 1	6144 x 3240	1 - 81 / 81	22.43 x 11.83 - ∅ 25.36
6K 2:1	2 : 1	6144 x 3072	1 - 85 / 85	22.43 x 11.21 - ∅ 25.08
6K WS	2.37 : 1	6144 x 2592	1 - 101 / 101	22.43 x 9.46 - ∅ 24.34
6K HD	1.78 : 1	5760 x 3240	1 - 81 / 81	21.02 x 11.83 - ∅ 24.12
6K 3:2	1.50 : 1	5760 x 3840	1 - 68 / 38	21.02 x 14.02 - ∅ 25.27
6K 4:3	1.33 : 1	5760 x 4320	1 - 61 / 30	21.02 x 15.77 - ∅ 26.28
6K 6:5	1.20 : 1	3888 x 3240	1 - 81 / 81	14.19 x 11.83 - ∅ 18.47
6K 4:1	4 : 1	6144 x 1536	1 - 169 / 169	22.43 x 5.61 - ∅ 23.12
6K 8:1	8 : 1	6144 x 768	1 - 333 / 333	22.43 x 2.80 - ∅ 22.60
5.5K FF	1.91 : 1	5632 x 2948	1 - 89 / 89	20.56 x 10.76 - ∅ 23.21
5.5K 2:1	2 : 1	5632 x 2816	1 - 93 / 93	20.56 x 10.28 - ∅ 22.99
5.5K WS	2.37 : 1	5632 x 2376	1 - 110 / 110	20.56 x 8.67 - ∅ 22.31
5.5K HD	1.78: 1	5376 x 3024	1 - 87 / 87	19.62 x 11.04 - ∅ 22.51
5.5K 4:1	4 : 1	5632 x 1408	1 - 185 / 185	20.56 x 5.14 - ∅ 21.19
5.5K 8:1	8 : 1	5632 x 704	1 - 364 / 364	20.56 x 2.57 - ∅ 20.72
5K FF	1.90 : 1	5120 x 2700	1 - 96 / 96	18.69 x 9.86 - ∅ 21.13
5K 2:1	2 : 1	5120 x 2560	1 - 102 / 102	18.69 x 9.34 - ∅ 20.89
5K WS	2.37 : 1	5120 x 2160	1 - 120 / 120	18.69 x 7.88 - ∅ 20.28
5K HD	1.78 : 1	4800 x 2700	1 - 96 / 96	17.52 x 9.86 - ∅ 20.10
5K 6:5	1.20 : 1	3240 x 2700	1 - 96 / 96	11.83 x 9.86 - ∅ 15.40
5K 4:1	4 : 1	5120 1280	1 - 200 / 200	18.69 x 4.67 - ∅ 19.26
5K 8:1	8 : 1	5120 x 640	1 - 390 / 390	18.39 x 2.34 - ∅ 18.84
4.5K FF	1.91 : 1	4608 x 2412	1 - 108 / 108	16.82 x 8.80 - ∅ 18.98
4.5K 2:1	2 : 1	4608 x 2304	1 - 113 / 113	16.82 x 8.41 - ∅ 18.81
4.5K WS	2.37 : 1	4608 x 1944	1 - 134 / 134	16.82 x 7.10 - ∅ 18.26
4.5K HD	1.82 : 1	4320 x 2376	1 - 110 / 110	15.77 x 8.67 - ∅ 18.00
4.5K 3:2	1.50 : 1	4320 x 2880	1 - 91 / 91	15.77 x 10.51 - ∅ 18.95
4.5K 4:3	1.33 : 1	4320 x 3240	1 - 81 / 81	15.77 x 11.83 - ∅ 19.71
4.5K 5:4	1.25 : 1	47320 x 3456	1 - 76 / 76	15.77 x 12.61 - ∅ 20.19
4.5K 4:1	4 : 1	4608 x 1152	1 - 225 / 225	16.82 x 4.20 - ∅ 17.34
4.5K 8:1	8 : 1	4608 x 576	1 - 400 / 400	16.82 x 2.10 - ∅ 16.95
4K FF	1.90 : 1	4096 x 2160	1 - 121 / 121	14.95 x 7.88 - ∅ 16.90
4K 2:1	2 : 1	4096 x 2048	1 - 127 / 127	14.95 x 7.48 - ∅ 16.72
4K WS	2.37 : 1	4096 x 1728	1 - 151 / 151	14.95 x 6.31 - ∅ 16.23
4K HD	1.78 : 1	3840 x 2160	1 - 121 / 121	14.02 x 7.88 - ∅ 16.08
4K 3:2	1.50 : 1	3840 x 2560	1 - 102 / 102	14.02 x 9.34 - ∅ 16.85
4K 4:3	1.33 : 1	3840 x 2880	1 - 91 / 91	14.02 x 10.51 - ∅ 17.52
4K 5:4	1.25 : 1	3840 x 3072	1 - 85 / 85	14.02 x 11.21 - ∅ 17.95
4K 6:5	1.20 : 1	2592 x 2160	1 - 121 / 121	9.46 x 7.88 - ∅ 12.31
4K 4:1	4 : 1	4096 x 1024	1 - 253 / 253	14.95 x 3.74 - ∅ 15.41
4K 8:1	8 : 1	4096 x 512	1 - 400 / 400	14.95 x 1.87 - ∅ 15.07
4K 1:1	1 : 1	4320 x 4320	1 - 30 / 30	15.77 x 15.77 - ∅ 22.30
3.5K FF	1.91 : 1	3584 x 1876	1 - 139 / 139	13.08 x 6.85 - ∅ 14.77
3.5K 2:1	2 : 1	3854 x 1792	1 - 145 / 145	13.08 x 6.54 - ∅ 14.62
3.5K WS	2.37 : 1	3584 x 1512	1 - 172 / 172	13.08 x 5.52 - ∅ 14.20
3.5K HD	1.78 : 1	3456 x 1944	1 - 134 / 134	12.61 x 7.10 - ∅ 14.47
3.5K 3:2	1.50 : 1	3360 x 2240	1 - 117 / 117	12.26 x 8.18 - ∅ 14.74
3.5K 4:3	1.33 : 1	3360 x 2520	1 - 104 / 104	12.26 x 9.20 - ∅ 15.33
3.5K 5:4	1.25 : 1	3360 x 2688	1 - 97 / 97	12.26 x 9.81 - ∅ 15.70
3.5K 4:1	4 : 1	3584 x 896	1 - 288 / 288	13.08 x 3.27 - ∅ 13.48
3.5K 8:1	8 : 1	3584 x 448	1 - 400 / 400	13.08 x 1.64 - ∅ 13.18
3K FF	1.90 : 1	3072 x 1620	1 - 160 / 160	11.21 x 5.91 - ∅ 12.67
3K 2:1	2 : 1	3072 x 1536	1 - 169 / 169	11.21 x 5.61 - ∅ 12.54
3K WS	2.37 : 1	3072 x 1296	1 - 200 / 200	11.21 x 4.73 - ∅ 12.17
3K HD	1.78 : 1	2880 x 1620	1 - 160 / 160	10.51 x 5.91 - ∅ 12.06
3K 3:2	1.50 : 1	2880 x 1920	1 - 136 / 136	10.51 x 7.01 - ∅ 12.63
3K 4:3	1.33 : 1	2880 x 2160	1 - 121 / 121	10.51 x 7.88 - ∅ 13.14
3K 5:4	1.25 : 1	2880 x 2304	1 - 113 / 113	10.51 x 8.41 - ∅ 13.46
3K 6:5	1.20 : 1	1944 x 1620	1 - 160 / 160	7.10 x 5.91 - ∅ 9.24
3K 4:1	4 : 1	3072 x 768	1 - 333 / 333	11.21 x 2.80 - ∅ 11.55
3K 8:1	8 : 1	3072 x 384	1 - 400 / 400	11.21 x 1.40 - ∅ 11.30
2.5K FF	1.91 : 1	2560 x 1340	1 - 192 / 192	9.34 x 4.89 - ∅ 10.54
2.5K 2:1	2 : 1	2560 x 1280	1 - 201 / 201	9.34 x 4.67 - ∅ 10.44
2.5K WS	2.37 : 1	2560 x 1080	1 - 237 / 237	9.34 x 3.94 - ∅ 10.14
2.5K HD	1.78 : 1	2304 x 1296	1 - 194 / 194	8.41 x 4.73 - ∅ 9.65
2.5K 3:2	1.50 : 1	2400 x 1600	1 - 161 / 161	8.76 x 5.84 - ∅ 10.53
2.5K 4:3	1.33 : 1	2400 x 1800	1 - 144 / 144	8.76 x 6.57 - ∅ 10.95
2.5K 5:4	1.25 : 1	2400 x 1920	1 - 135 / 135	8.76 x 7.01 - ∅ 11.22
2.5K 4:1	4 : 1	2560 x 640	1 - 393 / 393	9.34 x 2.34 - ∅ 9.63
2.5K 8:1	8 : 1	2560 x 320	1 - 400 / 400	9.34 x 1.17 - ∅ 9.41
2K FF	1.90 : 1	2048 x 1080	1 - 241 / 241	7.48 x 3.94 - ∅ 8.45
2K 2:1	2 : 1	2048 x 1024	1 - 253 / 253	7.48 x 3.74 - ∅ 8.36
2K WS	2.37 : 1	2048 x 864	1 - 301 / 301	7.48 x 3.15 - ∅ 8.12
2K HD	1.78 : 1	1920 x 1080	1 - 241 / 241	7.01 x 3.94 - ∅ 8.04
2K 3:2	1.50 : 1	1920 x 1280	1 - 203 / 203	7.01 x 4.67 - ∅ 8.42
2K 4:3	1.33 : 1	1920 x 1440	1 - 180 / 180	7.01 x 5.26 - ∅ 8.76
2K 5:4	1.25 : 1	1920 x 1536	1 - 169 / 169	7.01 x 5.61 - ∅ 8.98
2K 6:5	1.20 : 1	1296 x 1080	1 - 240 / 240	4.73 x 3.94 - ∅ 6.16
2K 4:1	4 : 1	2048 x 512	1 - 400 / 400	7.48 x 1.87 - ∅ 7.71
2K 8:1	8 : 1	2048 x 256	1 - 400 / 400	7.48 x 0.93 - ∅ 7.54

Technical Specifications

RED WEAPON 6K (CARBON FIBER)

RED WEAPON

Dynamic Range: 16.5+ Stops
19 Megapixels for Film, Photo and Print Campaigns
High Speed: 100 fps in 6K, 120 fps in 5K and up to 300 fps in 2K
RAW Recording 16-bit
ProRes Recording 4K & 2K
RAW & ProRes Recording Simultaneously
3D LUT, 1D LUT
Interchangeable OLPF
Automatic Sensor Calibration (Black Shading)

New Cooling System (Quieter Camera)
Two LCD/EVF Outputs
Built-in Microphones
New Color Science
Natural Color Reproduction, Especially for Skin Tones
Extended Highlights, Soft Roll-off
Correction of Over/Underexposure
Extremely Low-noise
Integrated 8x Electronic ND Filter (with RED Motion Mount)
Global Shutter (with RED Motion Mount)

Formate & FPS: RED WEAPON 6K

Format	Aspect Ratio	Resoultion	FPS	Dimensions (mm)
ANAMORPHIC	RED WEAPON cameras support ANAMORPHIC 1.3x and 2x with each format. The camera offers a 6:5 aspect ratio for each resolution. Using a 6:5 aspect ratio at 2x anamorphic gives you a 2.40:1 aspect ratio.
6K FF	1.94 : 1	6144 x 3160	1 - 83	30.72 x 15.80 - ∅ 34.55
6K 2:1	2 : 1	6144 x 3072	1 - 85	30.72 x 15.36 - ∅ 34.35
6K WS	2.37 : 1	6144 x 2592	1 - 100	30.72 x 12.96 - ∅ 33.34
6K HD	16 : 9	5568 x 3132	1 - 83	27.84 x 15.66 - ∅ 31.92
6K 6:5	6 : 5	3792 x 3160	1 - 83	18.96 x 15.80 - ∅ 24.68
6K 3:2	3 : 2	4752 x 3160	1 - 83	23.76 x 15.80- ∅ 28.53
6K 4:1	4 : 1	6144 x 1536	1 - 169	30.72 x 7.68 - ∅ 31.67
6K 8:1	8 : 1	6144 x 768	1 - 333	30.72 x 3.84 - ∅ 30.96
5.5K FF	1.89 : 1	5632 x 2948	1 - 89	28.16 x 14.74 - ∅ 31.78
5.5K 2:1	2 : 1	5632 x 2816	1 - 93	28.16 x 14.08 - ∅ 31.48
5.5K WS	2.37 : 1	5632 x 2376	1 - 110	28.16 x 11.88 - ∅ 30.56
5.5K HD	16 : 9	5376 x 3024	1 - 86	26.88 x 15.12 - ∅ 30.84
5.5K 4:1	4 : 1	5632 x 1408	1 - 184	28.16 x 7.04 - ∅ 29.03
5.5K 8:1	8 : 1	5632 x 704	1 - 360	28.16 x 3.52 - ∅ 28.38
5K FF	1.89 : 1	5120 x 2700	1 - 96	25.60 x 13.50 - ∅ 28.94
5K 2:1	2 : 1	5120 x 2560	1 - 101	25.60 x 12.80 - ∅ 28.62
5K WS	2.37 : 1	5120 x 2160	1 - 120	25.60 x 10.80 - ∅ 27.78
5K HD	16 : 9	4800 x 2700	1 - 96	24.00 x 13.50 - ∅ 27.54
5K 6:5	6 : 5	3240 x 2700	1 - 96	16.20 x 13.50 - ∅ 21.09
5K 4:1	4 : 1	5120 x 1280	1 - 200	25.60 x 6.40 - ∅ 26.39
5K 8:1	8 : 1	5120 x 640	1 - 390	25.60 x 3.20 - ∅ 25.80
4.5K FF	1.89 : 1	4608 x 2412	1 - 113	23.04 x 12.06 - ∅ 26.01
4.5K 2:1	2 : 1	4608 x 2304	1 - 113	23.04 x 11.52 - ∅ 25.76
4.5K WS	2.37 : 1	4608 x 1944	1 - 134	23.04 x 9.72 - ∅ 25.01
4.5K HD	16 : 9	4224 x 2376	1 - 110	21.12 x 11.88 - ∅ 24.23
4.5K 3:2	3 : 2	4320 x 2880	1 - 91	21.60 x 14.40 - ∅ 25.96
4.5K 4:1	4 : 1	4608 x 1152	1 - 225	23.04 x 5.76 - ∅ 23.75
4.5K 8:1	8 : 1	4608 x 576	1 - 400	23.04 x 2.88 - ∅ 23.22
4K FF	1.89 : 1	4096 x 2160	1 - 121	20.48 x 10.80 - ∅ 23.15
4K 2:1	2 : 1	4096 x 2048	1 - 127	20.48 x 10.24 - ∅ 22.90
4K WS	2.37 : 1	4096 x 1728	1 - 151	20.48 x 8.64 - ∅ 22.23
4K HD	16 : 9	3840 x 2160	1 - 121	19.20 x 10.80 - ∅ 22.03
4K 6:5	6 : 5	2592 x 2160	1 - 121	12.96 x 10.80 - ∅ 16.87
4K 3:2	3 : 2	3840 x 2560	1 - 102	19.20 x 12.80 - ∅ 23.08
4K 4:3	4 : 3	3840 x 2880	1 - 91	19.20 x 14.40 - ∅ 24.00
4K 5:4	5 : 4	3840 x 3072	1 - 85	19.20 x 15.36 - ∅ 24.59
4K 4:1	4 : 1	4096 x 1024	1 - 253	20.48 x 5.12 - ∅ 21.11
4K 8:1	8 : 1	4096 x 512	1 - 400	20.48 x 2.56 - ∅ 20.64
3.5K FF	1.91 : 1	3584 x 1876	1 - 139	17.92 x 9.38 - ∅ 20.23
3.5K 2:1	2 : 1	3584 x 1792	1 - 145	17.92 x 8.96 - ∅ 20.04
3.5K WS	2.37 : 1	3584 x 1512	1 - 172	17.92 x 7.56 - ∅ 19.45
3.5K HD	16 : 9	3456 x 1944	1 - 134	17.28 x 9.72 - ∅ 19.83
3.5K 3:2	3 : 2	3360 x 2240	1 - 117	16.80 x 11.20 - ∅ 20.19
3.5K 4:3	4 : 3	3360 x 2520	1 - 104	16.80 x 12.60 - ∅ 21.00
3.5K 5:4	5 : 4	3360 x 2688	1 - 97	16.80 x 13.44 - ∅ 21.51
3.5K 4:1	4 : 1	3584 x 896	1 - 288	17.92 x 4.48 - ∅ 18.47
3.5K 8:1	8 : 1	3584 x 448	1 - 400	17.92 x 2.24 - ∅ 18.06
3K FF	1.89 : 1	3072 x 1620	1 - 160	15.36 x 8.10 - ∅ 17.36
3K 2:1	2 : 1	3072 x 1536	1 - 169	15.36 x 7.68 - ∅ 17.17
3K WS	2.37 : 1	3072 x 1296	1 - 200	15.36 x 6.48 - ∅ 16.67
3K HD	16 : 9	2880 x 1620	1 - 160	14.40 x 8.10 - ∅ 16.52
3K 6:5	6 : 5	1944 x 1620	1 - 160	9.72 x 8.10 - ∅ 12.65
3K 3:2	3 : 2	2880 x 1920	1 - 136	14.40 x 9.60 - ∅ 17.31
3K 4:3	4 : 3	2880 x 2160	1 - 121	14.40 x 10.80 - ∅ 18.00
3K 5:4	5 : 4	2880 x 2304	1 - 113	14.40 x 11.52 - ∅ 18.44
3K 4:1	4 : 1	3072 x 768	1 - 333	15.36 x 3.84 - ∅ 15.83
3K 8:1	8 : 1	3072 x 384	1 - 400	15.36 x 1.92 - ∅ 15.48
2.5K FF	1.91 : 1	2560 x 1340	1 - 192	12.80 x 6.70 - ∅ 14.45
2.5K 2:1	2 : 1	2560 x 1280	1 - 201	12.80 x 6.40 - ∅ 14.31
2.5K WS	2.37 : 1	2560 x 1080	1 - 237	12.80 x 5.40 - ∅ 13.89
2.5K HD	16 : 9	2304 x 1296	1 - 194	11.52 x 6.48 - ∅ 13.22
2.5K 3:2	3 : 2	2400 x 1600	1 - 161	12.00 x 8.00 - ∅ 14.42
2.5K 4:3	4 : 3	2400 x 1800	1 - 144	12.00 x 9.00 - ∅ 15.00
2.5K 5:4	5 : 4	2400 x 1920	1 - 135	12.00 x 9.60 - ∅ 15.37
2.5K 4:1	4 : 1	2560 x 640	1 - 393	12.80 x 3.20 - ∅ 13.19
2.5K 8:1	8 : 1	2560 x 320	1 - 400	12.80 x 1.60 - ∅ 12.90
2K FF	1.89 : 1	2048 x 1080	1 - 241	10.24 x 5.40 - ∅ 11.58
2K 2:1	2 : 1	2048 x 1024	1 - 253	10.24 x 5.12 - ∅ 11.45
2K WS	2.37 : 1	2048 x 864	1 - 301	10.24 x 4.32 - ∅ 11.11
2K HD	16 : 9	1920 x 1080	1 - 241	9.60 x 5.40 - ∅ 11.01
2K 6:5	6 : 5	1296 x 1080	1 - 241	6.48 x 5.40 - ∅ 8.44
2K 3:2	3 : 2	1920 x 1280	1 - 203	9.60 x 6.40 - ∅ 11.54
2K 4:3	4 : 3	1920 x 1440	1 - 180	9.60 x 7.20 - ∅ 12.00
2K 5:4	5 : 4	1920 x 1536	1 - 169	9.60 x 7.68 - ∅ 12.29
2K 4:1	4 : 1	2048 x 512	1 - 400	10.24 x 2.56 - ∅ 10.56
2K 8:1	8 : 1	2048 x 256	1 - 400	10.24 x 1.28 - ∅ 10.32

Technical Specifications

	WEAPON 6K (CARBON FIBER)	SCARLET-W
Sensor	19.4 Megapixel RED DRAGON™	13.8 Megapixel RED DRAGON™
Pixel Array	6144 (h) x 3160 (v)	5120 (h) x 2700 (v)
S/N Ratio	80db	80db
Dynamic Range	16.5+ stops	16.5+ stops
Sensitivity	ISO 250 - 2000 Base Range ISO 250 - 12800 (Metadata)	ISO 250 - 2000 Base Range ISO 250 - 12800 (Metadata)
Lens Coverage	30.7mm (h) x 15.8mm (v) x 34.5mm (d)	25.6mm (h) x 13.5mm (v) x 28.9mm (d)
Lens Mounts	PL Canon EF/EF-S Nikon AF-D/AF-S Leica M Motion Mount PL and Canon EF/EF-S	PL Canon EF/EF-S Nikon AF-D/AF-S Leica M Motion Mount PL and Canon EF/EF-S
Film Format	S35+ S35 A35 S16	S35 A35 S16
Acquisition Formats	ANAMORPHIC 1.3x and 2x with each format 6K RAW 5.5K RAW 5K RAW 4.5K RAW 4K RAW 3.5K RAW 3K RAW 2.5K RAW 2K RAW 4K Apple ProRes 422 HQ, up to 29.97 fps 4K Apple ProRes 422, up to 29.97 fps 4K Apple ProRes 422 LT, up to 29.97 fps 2K Apple ProRes 4444 XQ, up to 120 fps 2K Apple ProRes 4444, up to 120 fps 2K Apple ProRes 422 HQ, up to 120 fps 2K Apple ProRes 422, up to 120 fps 2K Apple ProRes 422 LT, up to 120 fps Avid DNxHR (coming soon) Avid DNxHD (coming soon)	ANAMORPHIC 1.3x and 2x with each format 5K RAW 4.5K RAW 4K RAW 3.5K RAW 3K RAW 2.5K RAW 2K RAW 2K Apple ProRes 422 HQ, up to 60 fps 2K Apple ProRes 422, up to 60 fps 2K Apple ProRes 422 LT, up to 60 fps Avid DNxHR (coming soon) Avid DNxHD (coming soon)
Project Frame Rates	23.98, 24, 25, 29.97, 48, 50, 59.94, all resolutions	23.98, 24, 25, 29.97, 48, 50, 59.94, all resolutions
Recording	REDCODE RAW + QucikTime ProRes simultanous REDCODE RAW only QucikTime ProRes only	REDCODE RAW + QucikTime ProRes simultanous REDCODE RAW only QucikTime ProRes only
Max Data Rates	300 MB/s using RED MINI-MAG® (512GB & 1TB) 225 MB/s using RED MINI-MAG (120GB & 240GB)	140 MB/s using RED MINI-MAG®
Max Frame Rates	75 fps at 6K FF and 9:1 REDCODE 100 fps at 6K 2.4:1 and 9:1 REDCODE 96 fps at 5K FF and 8:1 REDCODE 120 fps at 5K 2.4:1 and 8:1 REDCODE 100 fps at 4.5K FF and 7:1 REDCODE 120 fps at 4.5K 2.4:1 and 7:1 REDCODE 120 fps at 4K FF and 6:1 REDCODE 150 fps at 4K 2.4:1 and 9:1 REDCODE 150 fps at 3K FF and 5:1 REDCODE 200 fps at 3K 2.4:1 and 5:1 REDCODE 240 fps at 2K FF and 4:1 REDCODE 300 fps at 2K 2.4:1 and 4:1 REDCODE	50 fps at 5K FF and 9:1 REDCODE 60 fps at 5K 2.4:1 and 9:1 REDCODE 100 fps at 4.5K FF and 14:1 REDCODE 120 fps at 4.5K 2.4:1 and 13:1 REDCODE 120 fps at 4K FF and 13:1 REDCODE 150 fps at 4K 2.4:1 and 15:1 REDCODE 150 fps at 3K FF and 10:1 REDCODE 200 fps at 3K 2.4:1 and 11:1 REDCODE 240 fps at 2K FF and 8:1 REDCODE 300 fps at 2K 2.4:1 and 8:1 REDCODE
REDCODE Settings Range from 2:1 up to 22:1	3:1 REDCODE for 6K (6144 x 3160) at 24 fps 7:1 REDCODE for 6K (6144 x 3160) at 60 fps 2:1 REDCODE for 5K (5120 x 2700) at 24 fps 5:1 REDCODE for 5K (5120 x 2700) at 60 fps 2:1 REDCODE for 4K (4096 x 2160) at 24 fps 3:1 REDCODE for 4K (4096 x 2160) at 60 fps	5:1 REDCODE for 5K (5120 x 2700) at 24 fps 9:1 REDCODE for 5K (5120 x 2700) at 48 fps 3:1 REDCODE for 4K (4096 x 2160) at 24 fps 7:1 REDCODE for 4K (4096 x 2160) at 60 fps
Delivery Formats	4K: DPX, TIFF, OpenEXR (RED via RRencode plugin) 2K : DPX, TIFF, OpenEXR (RED via RRencode plugin) 1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4	4K: DPX, TIFF, OpenEXR (RED via RRencode plugin) 2K : DPX, TIFF, OpenEXR (RED via RRencode plugin) 1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4
Program Output	HD-SDI Clean Feed 2K RGB, 1080p RGB or 4:2:2 720p 4:2:2 SMPTE Timecode, HANC Metadata 24-bit 48Khz Audio	HD-SDI Clean Feed 2K RGB, 1080p RGB or 4:2:2 720p 4:2:2 SMPTE Timecode, HANC Metadata 24-bit 48Khz Audio
Monitor Output	3G-SDI (HD-SDI) and HDMI® with DSMC² expander module 1080p RGB or 4:2:2, 720p RGB or 4:2:2 480p RGB or 4:2:2 (HDMI Only) SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio	3G-SDI (HD-SDI) and HDMI® with DSMC² expander module 1080p RGB or 4:2:2, 720p RGB or 4:2:2 480p RGB or 4:2:2 (HDMI Only) SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio
Digital Media	RED MINI-MAG SSD: 512GB & 1TB, 300 MB/s RED MINI-MAG SSD: 120GB & 240GB, 225 MB/s	RED MINI-MAG SSD: 120GB, 240GB, 512GB, 1TB
Monitoring Options	DSMC RED Touch 7.0" Touch LCD DSMC RED Touch 4.7" Touch LCD DSMC RED EVF(OLED) RED Pro 7" LCD" RED Touch 5", 7", 9" LCD BOMB EVF (LCOS) High Definition Viewfinder BOMB EVF (OLED) High Definition Viewfinder	DSMC RED Touch 7.0" Touch LCD DSMC RED Touch 4.7" Touch LCD DSMC RED EVF(OLED) RED Pro 7" LCD" RED Touch 5", 7", 9" LCD BOMB EVF (LCOS) High Definition Viewfinder BOMB EVF (OLED) High Definition Viewfinder
Color Management	Supports 33×33×33, 32×32×32, 26×26×26, and 17×17×17 3D LUTs Variable number of 3D LUT outputs with DSMC²™ expander module User programmable shaper 1D LUTs Tetrahedral interpolation, 16-bit process	Supports 17×17×17 3D LUTs Variable number of 3D LUT outputs with DSMC²™ expander module User programmable shaper 1D LUTs Tetrahedral interpolation, 16-bit processing
Audio	Integrated dual channel digital stereo microphones, uncompressed, 24-bit 48 kHz Optional 2 channels with DSMC² expander module, umcompressed 24-bit, 48KHz	Integrated dual channel digital stereo microphones, uncompressed, 24-bit 48 kHz Optional 2 channels with DSMC² expander module, umcompressed 24-bit, 48KHz
Remote Control	Integrated REDLINK® WiFi Ethernet, RS232, GPI Trigger	Integrated REDLINK® WiFi Ethernet, RS232, GPI Trigger
Weight	3.3lbs. (BRAIN® with Integrated Media Bay)	3.5lbs. (BRAIN® with Integrated Media Bay)
Construction	Carbon Fiber, Magnesium, Aluminum Alloy	Aluminium Alloy

RED EPIC, SCARLET (DRAGON SENSOR)

Image Rental - RED Epic, Scalet, RED Rocket, Dragon Sensor

RED EPIC DRAGON

Dynamic Range: 16.5+ Stops
19 megapixels for film, photo and print campaignsn
High Speed: 100 fps in 6K, 120 fps in 5K and up to 300 fps in 2K
RAW Recording 16-bit

EPIC – The tiny marvel →

New Color Science
Natural Color reproduction, especially for Skin tones
Extended Highlights, soft Roll-off
Correction of over/underexposure
Extremely low-noise, clean images at ISO 2000
Integrated 8x Electronic ND Filter (with RED Motion Mount)
Global Shutter (with RED Motion Mount)

Formats & FPS: RED EPIC DRAGON

Format	Aspect Ratio	Resoultion	FPS	Dimensions (mm)
ANAMORPHIC	EPIC DRAGON cameras support ANAMORPHIC 1.3x and 2x with each format
6K FF	1.94 : 1	6144 x 3160	1 - 83	30.72 x 15.80 - ∅ 34.55
6K 2:1	2 : 1	6144 x 3072	1 - 85	30.72 x 15.36 - ∅ 34.35
6K WS	2.37 : 1	6144 x 2592	1 - 100	30.72 x 12.96 - ∅ 33.34
6K HD	16 : 9	5568 x 3132	1 - 83	27.84 x 15.66 - ∅ 31.92
6K 6:5	6 : 5	3792 x 3160	1 - 83	18.96 x 15.80 - ∅ 24.68
6K 4:1	4 : 1	6144 x 1536	1 - 167	30.72 x 7.68 - ∅ 31.67
6K 8:1	8 : 1	6144 x 768	1 - 325	30.72 x 3.84 - ∅ 30.96
5.5K FF	1.89 : 1	5632 x 2948	1 - 89	28.16 x 14.74 - ∅ 31.78
5.5K 2:1	2 : 1	5632 x 2816	1 - 93	28.16 x 14.08 - ∅ 31.48
5.5K WS	2.37 : 1	5632 x 2376	1 - 110	28.16 x 11.88 - ∅ 30.56
5.5K HD	16 : 9	5376 x 3024	1 - 87	26.88 x 15.12 - ∅ 30.84
5.5K 4:1	4 : 1	5632 x 1408	1 - 185	28.16 x 7.04 - ∅ 29.03
5.5K 8:1	8 : 1	5632 x 704	1 - 364	28.16 x 3.52 - ∅ 28.38
5K FF	1.89 : 1	5120 x 2700	1 - 96	25.60 x 13.50 - ∅ 28.94
5K 2:1	2 : 1	5120 x 2560	1 - 102	25.60 x 12.80 - ∅ 28.62
5K WS	2.37 : 1	5120 x 2160	1 - 120	25.60 x 10.80 - ∅ 27.78
5K HD	16 : 9	4800 x 2700	1 - 96	24.00 x 13.50 - ∅ 27.54
5K 6:5	6 : 5	3240 x 2700	1 - 96	16.20 x 13.50 - ∅ 21.09
5K 4:1	4 : 1	5120 x 1280	1 - 201	25.60 x 6.40 - ∅ 26.39
5K 8:1	8 : 1	5120 x 1280	1 - 393	25.60 x 3.20 - ∅ 25.80
4.5K FF	1.89 : 1	4608 x 2432	1 - 108	23.04 x 12.16 - ∅ 26.05
4.5K 2:1	2 : 1	4608 x 2304	1 - 113	23.04 x 11.52 - ∅ 25.76
4.5K WS	2.37 : 1	4608 x 1944	1 - 134	23.04 x 9.72 - ∅ 25.00
4.5K HD	16 : 9	4224 x 2376	1 - 110	21.12 x 11.88 - ∅ 24.23
4.5K 3:2	3 : 2	4320 x 2880	1 - 91	21.60 x 14.40 - ∅ 25.96
4.5K 4:1	4 : 1	4608 x 1152	1 - 225	23.04 x 5.76 - ∅ 23.75
4.5K 8:1	8 : 1	4608 x 576	1 - 400	23.04 x 2.88 - ∅ 23.22
4K FF	1.89 : 1	4096 x 2160	1 - 121	20.48 x 10.80 - ∅ 23.15
4K 2:1	2 : 1	4096 x 2048	1 - 127	20.48 x 10.24 - ∅ 22.90
4K WS	2.37 : 1	4096 x 1728	1 - 151	20.48 x 8.64 - ∅ 22.23
4K HD	16 : 9	3840 x 2160	1 - 121	19.20 x 10.80 - ∅ 22.03
4K 6:5	6 : 5	2592 x 2160	1 - 121	12.96 x 10.80 - ∅ 16.87
4K 3:2	3 : 2	3840 x 2560	1 - 102	19.20 x 12.80 - ∅ 23.08
4K 4:3	4 : 3	3840 x 2880	1 - 91	19.20 x 14.40 - ∅ 24.00
4K 5:4	5 : 4	3840 x 3072	1 - 85	19.20 x 15.36 - ∅ 24.59
4K 4:1	4 : 1	4096 x 1024	1 - 253	20.48 x 5.12 - ∅ 21.11
4K 8:1	8 : 1	4096 x 512	1 - 400	20.48 x 2.56 - ∅ 20.64
3.5K FF	1.91 : 1	3584 x 1876	1 - 139	17.92 x 9.38 - ∅ 20.23
3.5K 2:1	2 : 1	3584 x 1792	1 - 145	17.92 x 8.96 - ∅ 20.04
3.5K WS	2.37 : 1	3584 x 1512	1 - 172	17.92 x 7.56 - ∅ 19.45
3.5K HD	16 : 9	3456 x 1944	1 - 134	17.28 x 9.72 - ∅ 19.83
3.5K 3:2	3 : 2	3360 x 2240	1 - 117	16.80 x 11.20 - ∅ 20.19
3.5K 4:3	4 : 3	3360 x 2520	1 - 104	16.80 x 12.60 - ∅ 21.00
3.5K 5:4	5 : 4	3360 x 2688	1 - 97	16.80 x 13.44 - ∅ 21.51
3.5K 4:1	4 : 1	3584 x 896	1 - 288	17.92 x 4.48 - ∅ 21.11
3.5K 8:1	8 : 1	3584 x 448	1 - 400	17.92 x 2.24 - ∅ 20.64
3K FF	1.89 : 1	3072 x 1620	1 - 160	15.36 x 8.10 - ∅ 17.36
3K 2:1	2 : 1	3072 x 1536	1 - 169	15.36 x 7.68 - ∅ 17.17
3K WS	2.37 : 1	3072 x 1296	1 - 200	15.36 x 6.48 - ∅ 16.67
3K HD	16 : 9	2880 x 1620	1 - 160	14.40 x 8.10 - ∅ 16.52
3K 6:5	6 : 5	1944 x 1620	1 - 160	9.72 x 8.10 - ∅ 12.65
3K 3:2	3 : 2	2880 x 1920	1 - 136	14.40 x 9.60 - ∅ 17.31
3K 4:3	4 : 3	2880 x 2160	1 - 121	14.40 x 10.80 - ∅ 18.00
3K 5:4	5 : 4	2880 x 2304	1 - 113	14.40 x 11.52 - ∅ 18.44
3K 4:1	4 : 1	3072 x 768	1 - 333	15.36 x 3.84 - ∅ 15.83
3K 8:1	8 : 1	3072 x 384	1 - 400	15.36 x 1.92 - ∅ 15.48
2.5K FF	1.91 : 1	2560 x 1340	1 - 192	12.80 x 6.70 - ∅ 14.45
2.5K 2:1	2 : 1	2560 x 1280	1 - 201	12.80 x 6.40 - ∅ 14.31
2.5K WS	2.37 : 1	2560 x 1080	1 - 237	12.80 x 5.40 - ∅ 13.89
2.5K HD	16 : 9	2304 x 1296	1 - 194	11.52 x 6.48 - ∅ 13.22
2.5K 3:2	3 : 2	2400 x 1600	1 - 161	12.00 x 8.00 - ∅ 14.42
2.5K 4:3	4 : 3	2400 x 1800	1 - 144	12.00 x 9.00 - ∅ 15.00
2.5K 5:4	5 : 4	2400 x 1920	1 - 135	12.00 x 9.60 - ∅ 15.37
2.5K 4:1	4 : 1	2560 x 640	1 - 393	12.80 x 3.20 - ∅ 13.19
2.5K 8:1	8 : 1	2560 x 320	1 - 400	12.80 x 1.60 - ∅ 12.90
2K FF	1.89 : 1	2048 x 1080	1 - 240	10.24 x 5.40 - ∅ 11.58
2K 2:1	2 : 1	2048 x 1024	1 - 253	10.24 x 5.12 - ∅ 11.45
2K WS	2.37 : 1	2048 x 864	1 - 298	10.24 x 4.32 - ∅ 11.11
2K HD	16 : 9	1920 x 1080	1 - 240	9.60 x 5.40 - ∅ 11.01
2K 6:5	6 : 5	1296 x 1080	1 - 240	6.48 x 5.40 - ∅ 8.44
2K 3:2	3 : 2	1920 x 1280	1 - 203	9.60 x 6.40 - ∅ 11.54
2K 4:3	4 : 3	1920 x 1440	1 - 180	9.60 x 7.20 - ∅ 12.00
2K 5:4	5 : 4	1920 x 1536	1 - 169	9.60 x 7.68 - ∅ 12.29
2K 4:1	4 : 1	2048 x 512	1 - 400	10.24 x 2.56 - ∅ 10.56
2K 8:1	8 : 1	2048 x 256	1 - 400	10.24 x 1.28 - ∅ 10.32

Technical Specifications

EPIC, SCARLET, RED ONE (MYSTERIUM-X Sensor)

EPIC – The tiny marvel →

Ready to shoot in 11 seconds

Dynamic Range: 13.5 – 18 Stops HDRx
Dimension of a Hasselblad still camera
14 Megapixel für Film, Foto und Printkampagnen
Simple Touchscreen menu
High Speed: 120 fps in 5K and up to 300 fps in 2K
RAW Recording 16-bit
3D optimized
Titanium PL-Mount

Formats & FPS

Format	Aspect Ratio	Resoultion	FPS EPIC M-X	FPS SCARLET M-X	DIMENSIONS (MM)
5K FF	1.89 : 1	5120 x 2700	1 - 96	1 - 12	27.65 x 14.58 - ∅ 31.26
5K FF	Anamorphic 1.3x, 2.47:1	5120 x 2700	1 - 96	1 - 12	27.65 x 14.58 - ∅ 31.26
5K FF	Anamorphic 2x, 3.79:1	5120 x 2700	1 - 96	1 - 12	27.65 x 14.58 - ∅ 31.26
5K 2:1	2 : 1	5120 x 2560	1 - 101	1 - 12	27.65 x 13.82 - ∅ 30.91
5K WS	2.37 : 1	5120 x 2160	1 - 121	1 - 12	27.65 x 11.66 - ∅ 30.01
5K HD	16 : 9	4800 x 2700	1 - 96	1 - 12	25.92 x 13.82 - ∅ 29.37
5K 1.2:1	1.22 : 1	3300 x 2700	1 - 96	1 - 12	17.82 x 13.82 - ∅ 22.55
5K 1.2:1	Anamorphic 2x, 2.44:1	3296 x 2700	1 - 96	1 - 12	17.80 x 13.82 - ∅ 22.53
4K FF	1.89 : 1	4096 x 2160	1 - 121	1 - 30	22.12 x 11.66 - ∅ 25.01
4K WS	2.39 : 1	4096 x 1708	1 - 152	1 - 36	22.12 x 9.22 - ∅ 23.97
4K HD	16 : 9	3840 x 2160	1 - 121	1 - 30	20.74 x 11.66 - ∅ 23.79
3K FF	1.89 : 1	3072 x 1620	1 - 160	1 - 48	16.59 x 8.75 - ∅ 18.76
3K WS	2.39 : 1	3072 x 1284	1 - 201	1 - 60	16.59 x 6.93 - ∅ 17.98
3K HD	16 : 9	2880 x 1620	1 - 160	1 - 48	15.55 x 8.75 - ∅ 17.84
2K FF	1.89 : 1	2048 x 1080	1 - 240	1 - 60	11.06 x 5.83 - ∅ 12.50
2K WS	2.39 : 1	2048 x 854	1 - 302	1 - 75	11.06 x 4.61 - ∅ 11.98
2K HD	16 : 9	1920 x 1080	1 - 240	1 - 60	10.37 x 5.83 - ∅ 11.90
1K HD	16 : 9	1280 x 720	1 - 357	1 - 90	6.91 x 3.89 - ∅ 7.93
1K WS	2.66 : 1	1280 x 480	1 - 400	1 - 120	6.91 x 2.59 - ∅ 7.38

Format	Aspect Ratio	Resoultion	FPS RED ONE M-X	DIMENSIONS (MM)
4.5K WS	2.33 : 1	4480 x 1920	1 - 30	24.19 x 10.37 - ∅ 26.32
4K ANA	Anamorphic 2:1	2816 x 2304	1 - 30	15.21 x 12.44 - ∅ 19.65
4K 16:9	16 : 9	4096 x 2304	1 - 30	22.12 x 12.44 - ∅ 25.34
4K HD	16 : 9	3840 x 2160	1 - 30	20.74 x 11.66 - ∅ 23.79
4K 2:1	2 : 1	4096 x 2048	1 - 30	22.12 x 11.06 - ∅ 24.73
3K ANA	Anamorphic 2:1	2112 x 1728	1 - 60	11.41 x 9.33 - ∅ 14.74
3K 16:9	16 : 9	3072 x 1728	1 - 50	16.59 x 9.33 - ∅ 19.03
3K 2:1	2 : 1	3072 x 1536	1 - 60	16.59 x 8.29 - ∅ 18.55
2K ANA	Anamorphic 2:1	1408 x 1152	1 - 120	7.60 x 6.22 - ∅ 9.82
2K 16:9	16 : 9	2048 x 1152	1 - 100	11.06 x 6.22 - ∅ 12.69
2K 2:1	2 : 1	2048 x 1024	1 - 120	11.06 x 5.53 - ∅ 12.37

Technical Specifications

	EPIC Mysterium-X	SCARLET Mysterium-X	RED ONE M-X
Sensor	14 MEGAPIXEL MYSTERIUM-X™ (Super 35mm)	14 MEGAPIXEL MYSTERIUM-X™ (Super 35mm)	14 MEGAPIXEL MYSTERIUM-X™ (Super 35mm)
Pixel Array	5120 (h) x 2700 (v)	5120 (h) x 2700 (v)	5120 (h) x 2700 (v)
S/N Ratio	66db	66db	66db
Dynamic Range	13.5 stops, up to 18 stops with HDRx™	13.5 stops, up to 18 stops with HDRx™	13+ stops
Sensitivity	ISO 800 Base ISO 250 - 12800 (Metadata)	ISO 800 Base ISO 250 - 12800 (Metadata)	ISO 800 Base ISO 100 - 6400 (Metadata)
Lens Coverage	27.7mm (h) x 14.6mm (v) x 31.4mm (d)	27.7mm (h) x 14.6mm (v) x 31.4mm (d)	24.2mm (h) x 12.5mm (v) x 27.3mm (d)
Lens Mounts	PL Canon EF/EF-S Nikon AF-D/AF-S Leica M	PL Canon EF/EF-S Nikon AF-D/AF-S Leica M	PL Birger Canon EF
Depth of Field	Equivalent to S35mm (Motion) / APS-H (Still) lenses Equivalent to 16mm (Motion) in 2K RAW	Equivalent to S35mm (Motion) / APS-H (Still) lenses Equivalent to 16mm (Motion) in 2K RAW	Equivalent to S35mm (Motion) / Equivalent to 16mm (Motion) in 2K RAW
Acquisition Formats	5K RAW 4K RAW 3K RAW 2K RAW 1K RAW	5K RAW 4K RAW 3K RAW 2K RAW 1K RAW	4.5K RAW 4K RAW 3K RAW 2K RAW
Project Frame Rates	23.98, 24, 25, 29.97, 48, 50, 59.94, all resolutions	23.98, 24, 25, 29.97, 48, 50, 59.94, all resolutions	23.98, 24, 25, 29.97 fps @ 4.5K, 4K plus 50, 59.94 fps @ 3K, 2K
Delivery Formats	4K: DPX, TIFF, OpenEXR (RED Ray via optional encoder) 2K : DPX, TIFF, OpenEXR (RED RAY via optional encoder) 1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4	4K: DPX, TIFF, OpenEXR (RED Ray via optional encoder) 2K : DPX, TIFF, OpenEXR (RED RAY via optional encoder) 1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4	4K: DPX, TIFF, OpenEXR (RED Ray via optional encoder) 2K : DPX, TIFF, OpenEXR (RED RAY via optional encoder) 1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4
Program Output	HD-SDI Clean Feed 2K RGB, 1080p RGB or 4:2:2 720p 4:2:2 SMPTE Timecode, HANC Metadata 24-bit 48Khz Audio	HD-SDI Clean Feed 2K RGB, 1080p RGB or 4:2:2 720p 4:2:2 SMPTE Timecode, HANC Metadata 24-bit 48Khz Audio	---
Monitor Output	HD-SDI and HDMI with Frame Guides and Look Around 2K RGB 1080p RGB or 4:2:2 720p RGB or 4:2:2 SMPTE Timecode HANC Metadata 24-bit 48Khz Audio	HD-SDI and HDMI with Frame Guides and Look Around 2K RGB 1080p RGB or 4:2:2 720p RGB or 4:2:2 SMPTE Timecode HANC Metadata 24-bit 48Khz Audio	HD-SDI and HDMI with Frame Guides and Look Around 720p RGB or 4:2:2 SMPTE Timecode HANC Metadata 24-bit 48Khz Audio
Digital Media	REDMAG 1.8'' SSD Module: (64, 128, 256, 512GB Media)	REDMAG 1.8'' SSD Module: (64, 128, 256, 512GB Media)	RED SSD™ (64GB, 128GB, 256, 512GB Media)
REDCODE™	16-bit RAW: Compression choices of 18:1 to 3:1 1-120 fps 5K 1-120 fps 4K 1-160 fps 3K 1-300 fps 2K 1-400 fps 1K	16-bit RAW: Compression choices of 18:1 to 3:1 1-12 fps 5K FF 1-30 fps 4K 1-48 fps 3K 1-60 fps 1080p HD 1-120 fps 1K	12-bit RAW: RC28, 36, 42 Quality Levels 1-30 fps 4.5K, 4K 1-60 fps 3K 1-120 fps 2K
Audio	2 channel, uncompressed, 24 bit, 48KHz Optional 4 channel and AES / EBU digital audio	2 channel, uncompressed, 24 bit, 48KHz Optional 4 channel and AES / EBU digital audio	4 channel, uncompressed, 24 bit, 48KHz
Monitoring Options	RED LCD 5", 9" Touchscreen Display BOMB EVF™ High Definition Viewfinder	RED LCD 5", 9" Touchscreen Display BOMB EVF™ High Definition Viewfinder	RED LCD 5" Flat Panel Display RED PRO LCD 7" Flat Panel Display BOMB EVF™ High Definition Viewfinder
Remote Control	REDLINK Wireless, Ethernet, RS232, GPI Trigger	REDLINK Wireless, Ethernet, RS232, GPI Trigger	USB-2, GPI Trigger
Weight	5lbs. Body only	5lbs. Body only	10lbs. Body only
Construction	Aluminium Alloy	Aluminium Alloy	Aluminium Alloy

-Top-

	WEAPON 8K S35 HELIUM	EPIC-W 8K S35 HELIUM
Sensor	35.4 Megapixel RED HELIUM™	35.4 Megapixel RED HELIUM™
Pixel Array	8192 (h) x 4320 (v)	8192 (h) x 4320 (v)
S/N Ratio	80db	80db
Dynamic Range	16.5+ stops	16.5+ stops
Sensitivity	ISO 500 - 4000 Base Range ISO 250 - 12800 (Metadata)	ISO 500 - 4000 Base Range ISO 250 - 12800 (Metadata)
Lens Coverage	29.90mm (h) x 15.77mm (v) x 33.80mm (d)	29.90mm (h) x 15.77mm (v) x 33.80mm (d)
Lens Mounts	PL Canon EF/EF-S Nikon AF-D/AF-S Leica M Motion Mount PL and Canon EF/EF-S	PL Canon EF/EF-S Nikon AF-D/AF-S Leica M Motion Mount PL and Canon EF/EF-S
Film Format	S35+ S35 A35 S16	S35+ S35 A35 S16
Acquisition Formats	ANAMORPHIC 1.3x and 2x with each format 8K RAW 7.5K RAW 7K RAW 6.5K RAW 6K RAW 5.5K RAW 5K RAW 4.5K RAW 4K RAW 3.5K RAW 3K RAW 2.5K RAW 2K RAW 4K Apple ProRes 422 HQ, up to 29.97 fps 4K Apple ProRes 422, up to 29.97 fps 4K Apple ProRes 422 LT, up to 29.97 fps 2K Apple ProRes 4444 XQ, up to 120 fps 2K Apple ProRes 4444, up to 120 fps 2K Apple ProRes 422 HQ, up to 120 fps 2K Apple ProRes 422, up to 120 fps 2K Apple ProRes 422 LT, up to 120 fps DNxHR HQX, up to 29.97 fps DNxHR HQ, up to 29.97 fps DNxHR SQ, up to 29.97 fps DNxHR LB, up to 29.97 fps DNxHR 444, up to 120 fps DNxHD 444, up to 120 fps DNxHD HQX, up to 120 fps DNxHD HQ, up to 120 fps DNxHD SQ, up to 120 fps DNxHD LB, up to 120 fps	ANAMORPHIC 1.3x and 2x with each format 8K RAW 7.5K RAW 7K RAW 6.5K RAW 6K RAW 5.5K RAW 5K RAW 4.5K RAW 4K RAW 3.5K RAW 3K RAW 2.5K RAW 2K RAW 4K Apple ProRes 422 HQ, up to 29.97 fps 4K Apple ProRes 422, up to 29.97 fps 4K Apple ProRes 422 LT, up to 29.97 fps 2K Apple ProRes 4444 XQ, up to 120 fps 2K Apple ProRes 4444, up to 120 fps 2K Apple ProRes 422 HQ, up to 120 fps 2K Apple ProRes 422, up to 120 fps 2K Apple ProRes 422 LT, up to 120 fps DNxHR HQX, up to 29.97 fps DNxHR HQ, up to 29.97 fps DNxHR SQ, up to 29.97 fps DNxHR LB, up to 29.97 fps DNxHR 444, up to 120 fps DNxHD 444, up to 120 fps DNxHD HQX, up to 120 fps DNxHD HQ, up to 120 fps DNxHD SQ, up to 120 fps DNxHD LB, up to 120 fps
Project Frame Rates	23.98, 24, 25, 29.97, 48, 50, 59.94, all resolutions	23.98, 24, 25, 29.97, 48, 50, 59.94, all resolutions
Recording	REDCODE RAW + QucikTime ProRes simultanous REDCODE RAW + Avid Codecs simulanous REDCODE RAW only QucikTime ProRes only Avid Codec only	REDCODE RAW + QucikTime ProRes simultanous REDCODE RAW + Avid Codecs simulanous REDCODE RAW only QucikTime ProRes only Avid Codec only
Max Data Rates	300 MB/s using RED MINI-MAG® (512GB & 1TB) 225 MB/s using RED MINI-MAG (120GB & 240GB)	275 MB/s using RED MINI-MAG® (512GB & 1TB) 225 MB/s using RED MINI-MAG (120GB & 240GB)
Max Frame Rates	60 fps at 8K FF and 12:1 REDCODE 75 fps at 8K 2.4:1 and 12:1 REDCODE 60 fps at 7K FF and 10:1 REDCODE 75 fps at 7K 2.4:1 and 10:1 REDCODE 75 fps at 6K FF and 9:1 REDCODE 100 fps at 6K 2.4:1 and 9:1 REDCODE 96 fps at 5K FF and 8:1 REDCODE 120 fps at 5K 2.4:1 and 8:1 REDCODE 100 fps at 4.5K FF and 7:1 REDCODE 120 fps at 4.5K 2.4:1 and 7:1 REDCODE 120 fps at 4K FF and 6:1 REDCODE 150 fps at 4K 2.4:1 and 7:1 REDCODE 150 fps at 3K FF and 5:1 REDCODE 200 fps at 3K 2.4:1 and 5:1 REDCODE 240 fps at 2K FF and 4:1 REDCODE 300 fps at 2K 2.4:1 and 4:1 REDCODE	30 fps at 8K FF and 7:1 REDCODE 30 fps at 8K 2.4:1 and 7:1 REDCODE 30 fps at 7K FF and 7:1 REDCODE 40 fps at 7K 2.4:1 and 7:1 REDCODE 75 fps at 6K FF and 12:1 REDCODE 100 fps at 6K 2.4:1 and 12:1 REDCODE 96 fps at 5K FF and 10:1 REDCODE 120 fps at 5K 2.4:1 and 10:1 REDCODE 100 fps at 4.5K FF and 9:1 REDCODE 120 fps at 4.5K 2.4:1 and 9:1 REDCODE 120 fps at 4K FF and 8:1 REDCODE 150 fps at 4K 2.4:1 and 9:1 REDCODE 150 fps at 3K FF and 6:1 REDCODE 200 fps at 3K 2.4:1 and 7:1 REDCODE 240 fps at 2K FF and 5:1 REDCODE 300 fps at 2K 2.4:1 and 5:1 REDCODE
REDCODE Settings Range from 2:1 up to 22:1	5:1 REDCODE for 8K Full Frame (8192 x 4320) at 24 fps 12:1 REDCODE for 8K Full Frame (8192 x 4320) at 30 fps 2:1 REDCODE for 4K Full Frame (4096 x 2160) at 24 fps 3:1 REDCODE for 4K Full Frame (4096 x 2160) at 60 fps	6:1 REDCODE for 8K Full Frame (8192 x 4320) at 24 fps 7:1 REDCODE for 8K Full Frame (8192 x 4320) at 30 fps 2:1 REDCODE for 4K Full Frame (4096 x 2160) at 24 fps 4:1 REDCODE for 4K Full Frame (4096 x 2160) at 60 fps
Delivery Formats	4K: DPX, TIFF, OpenEXR (RED via RRencode plugin) 2K : DPX, TIFF, OpenEXR (RED via RRencode plugin) 1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4	4K: DPX, TIFF, OpenEXR (RED via RRencode plugin) 2K : DPX, TIFF, OpenEXR (RED via RRencode plugin) 1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4
Program Output	HD-SDI Clean Feed 2K RGB, 1080p RGB or 4:2:2 720p 4:2:2 SMPTE Timecode, HANC Metadata 24-bit 48Khz Audio	HD-SDI Clean Feed 2K RGB, 1080p RGB or 4:2:2 720p 4:2:2 SMPTE Timecode, HANC Metadata 24-bit 48Khz Audio
Monitor Output	3G-SDI (HD-SDI) and HDMI® with DSMC² expander module 1080p RGB or 4:2:2, 720p RGB or 4:2:2 480p RGB or 4:2:2 (HDMI Only) SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio	3G-SDI (HD-SDI) and HDMI® with DSMC² expander module 1080p RGB or 4:2:2, 720p RGB or 4:2:2 480p RGB or 4:2:2 (HDMI Only) SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio
Digital Media	RED MINI-MAG SSD: 512GB & 1TB, 300 MB/s RED MINI-MAG SSD: 120GB & 240GB, 225 MB/s	RED MINI-MAG SSD: 512GB & 1TB, 275 MB/s RED MINI-MAG SSD: 120GB & 240GB, 225 MB/s
Monitoring Options	DSMC RED Touch 7.0" Touch LCD DSMC RED Touch 4.7" Touch LCD DSMC RED EVF(OLED) RED Pro 7" LCD" RED Touch 5", 7", 9" LCD BOMB EVF (LCOS) High Definition Viewfinder BOMB EVF (OLED) High Definition Viewfinder	DSMC RED Touch 7.0" Touch LCD DSMC RED Touch 4.7" Touch LCD DSMC RED EVF(OLED) RED Pro 7" LCD" RED Touch 5", 7", 9" LCD BOMB EVF (LCOS) High Definition Viewfinder BOMB EVF (OLED) High Definition Viewfinder
Color Management	Supports 33×33×33, 32×32×32, 26×26×26, and 17×17×17 3D LUTs Variable number of 3D LUT outputs with DSMC²™ expander module User programmable shaper 1D LUTs Tetrahedral interpolation, 16-bit process	Supports 33x33x33, 32x32x32, 26x26x26, 17×17×17 3D LUTs Variable number of 3D LUT outputs with DSMC²™ expander module User programmable shaper 1D LUTs Tetrahedral interpolation, 16-bit processing
Audio	Integrated dual channel digital stereo microphones, uncompressed, 24-bit 48 kHz Optional 2 channels with DSMC² expander module, umcompressed 24-bit, 48KHz	Integrated dual channel digital stereo microphones, uncompressed, 24-bit 48 kHz Optional 2 channels with DSMC² expander module, umcompressed 24-bit, 48KHz
Remote Control	Integrated REDLINK® WiFi Ethernet, RS232, GPI Trigger	Integrated REDLINK® WiFi Ethernet, RS232, GPI Trigger
Weight	3.3lbs. (BRAIN® with Integrated Media Bay)	3.5lbs. (BRAIN® with Integrated Media Bay)
Construction	Carbon Fiber, Magnesium, Aluminum Alloy	Magnesium, Aluminium Alloy

	EPIC DRAGON	SCARLET DRAGON
Sensor	19 MEGAPIXEL RED DRAGON™	19 MEGAPIXEL RED DRAGON™
Pixel Array	6144 (h) x 3160 (v)	6144 (h) x 3160 (v)
S/N Ratio	80db	80db
Dynamic Range	16.5+ stops	16.5+ stops
Sensitivity	ISO 250 - 2000 Base Range ISO 250 - 12800 (Metadata)	ISO 250 - 2000 Base Range ISO 250 - 12800 (Metadata)
Lens Coverage	30.7mm (h) x 15.8mm (v) x 34.5mm (d)	30.7mm (h) x 15.8mm (v) x 34.5mm (d)
Lens Mounts	PL Canon EF/EF-S Nikon AF-D/AF-S Leica M Motion Mount PL and Canon EF/EF-S	PL Canon EF/EF-S Nikon AF-D/AF-S Leica M Motion Mount PL and Canon EF/EF-S
Depth of Field	Equivalent to S35mm (Motion) / APS-H (Still) lenses Equivalent to 16mm (Motion) in 2K RAW	Equivalent to S35mm (Motion) / APS-H (Still) lenses Equivalent to 16mm (Motion) in 2K RAW
Acquisition Formats	6K RAW 5.5K RAW 5K RAW 4.5K RAW 4K RAW 3.5K RAW 3K RAW 2.5K RAW 2K RAW	6K RAW 5K RAW 4K RAW 3K RAW 2K RAW
Project Frame Rates	23.98, 24, 25, 29.97, 48, 50, 59.94, all resolutions	23.98, 24, 25, 29.97, 48, 50, 59.94, all resolutions
Delivery Formats	4K: DPX, TIFF, OpenEXR (RED Ray via optional encoder) 2K : DPX, TIFF, OpenEXR (RED RAY via optional encoder) 1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4	4K: DPX, TIFF, OpenEXR (RED Ray via optional encoder) 2K : DPX, TIFF, OpenEXR (RED RAY via optional encoder) 1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4
Program Output	HD-SDI Clean Feed 2K RGB, 1080p RGB or 4:2:2 720p 4:2:2 SMPTE Timecode, HANC Metadata 24-bit 48Khz Audio	HD-SDI Clean Feed 2K RGB, 1080p RGB or 4:2:2 720p 4:2:2 SMPTE Timecode, HANC Metadata 24-bit 48Khz Audio
Monitor Output	HD-SDI and HDMI with Frame Guides and Look Around 2K RGB 1080p RGB or 4:2:2 720p RGB or 4:2:2 SMPTE Timecode HANC Metadata 24-bit 48Khz Audio	HD-SDI and HDMI with Frame Guides and Look Around 2K RGB 1080p RGB or 4:2:2 720p RGB or 4:2:2 SMPTE Timecode HANC Metadata 24-bit 48Khz Audio
Digital Media	RED MINI-MAG SSD: 512GB (fastest media, less compression at high fps) REDMAG 1.8'' SSD Module: (48, 64, 128, 240, 256, 512GB Media)	RED MINI-MAG SSD: 512GB (fastest media, less compression at high fps) REDMAG 1.8'' SSD Module: (48, 64, 128, 240, 256, 512GB Media)
REDCODE™ FPS	16-bit RAW: Compression choices of 18:1 to 2:1 1-100 fps 6K 1-110 fps 5.5K 1-120 fps 5K 1-134 fps 4.5K 1-150 fps 4K 1-172 fps 3.5K 1-200 fps 3K 1-237 fps 2.5K 1-300 fps 2K	16-bit RAW: Compression choices of 18:1 to 2:1 6K FF: 12 FPS (in Burst mode) 5K FF: 48 FPS 4K FF: 60 FPS 3K FF: 80 FPS 2K FF: 120 FPS 5K 2.4:1: 60 FPS 4K 2.4:1: 75 FPS 3K 2.4:1: 100 FPS 2K 2.4:1: 150 FPS
Audio	2 channel, uncompressed, 24 bit, 48KHz Optional 4 channel and AES / EBU digital audio	2 channel, uncompressed, 24 bit, 48KHz Optional 4 channel and AES / EBU digital audio
Monitoring Options	RED LCD 5", 9" Touchscreen Display BOMB EVF™ High Definition Viewfinder	RED LCD 5", 9 Touchscreen Display BOMB EVF™ High Definition Viewfinder
Remote Control	REDLINK Wireless, Ethernet, RS232, GPI Trigger	REDLINK Wireless, Ethernet, RS232, GPI Trigger
Weight	5lbs. Body only	5lbs. Body only
Construction	Aluminium Alloy	Aluminium Alloy

RED WEAPON MONSTRO 8K VV SENSOR

RED WEAPON MONSTRO 8K VV

Formate & FPS: RED WEAPON MONSTRO 8K VV

Format

Aspect Ratio

Resolution

FPS (MONSTRO 8K VV)

Dimensions (mm)

Technische Spezifikationen

RED Weapon 8K VV MONSTRO

RED HELIUM 8K S35 Sensor

RED WEAPON & EPIC-W

Formats & FPS: RED WEAPON & EPIC-W 8K

Format

Aspect Ratio

Resoultion

FPS (WEAPON/EPIC-W)

Dimensions (mm)

Technical Specifications

WEAPON 8K S35 HELIUM

EPIC-W 8K S35 HELIUM

RED WEAPON 6K (CARBON FIBER)

RED WEAPON

Formate & FPS: RED WEAPON 6K

Format

Aspect Ratio

Resoultion

FPS

Dimensions (mm)

Technical Specifications

WEAPON 6K (CARBON FIBER)

SCARLET-W

RED EPIC, SCARLET (DRAGON SENSOR)

RED EPIC DRAGON

EPIC – The tiny marvel →

Formats & FPS: RED EPIC DRAGON

Format

Aspect Ratio

Resoultion

FPS

Dimensions (mm)

Technical Specifications

EPIC DRAGON

SCARLET DRAGON

EPIC, SCARLET, RED ONE (MYSTERIUM-X Sensor)

EPIC – The tiny marvel →

Ready to shoot in 11 seconds

Formats & FPS

Format

Aspect Ratio

Resoultion

FPS EPIC M-X

FPS SCARLET M-X

DIMENSIONS (MM)

Format

Aspect Ratio

Resoultion

FPS RED ONE M-X

DIMENSIONS (MM)

Technical Specifications

EPIC Mysterium-X

SCARLET Mysterium-X

RED ONE M-X

FPS EPIC
M-X

FPS SCARLET
M-X
