SC Canon C80 – Base Set

From: 1,264.00 $ excl. VAT

The SWISS cage Production packages are the professional support set-up for your camera of choice. Base Set.

Product

Quantity

SC-micro-PWR-mounts_V-Gold-Mount_OCTAMAS-gear00001

Optional - Micro Power Plate

Add for 386.00 $ excl. VAT

1

SC-micro-PB_V_GOLD_mount_OCTAMAS-gear00001

Optional - Power Box Pro Micro

Add for 696.00 $ excl. VAT

1

2_5_3_5mm-Jack-LANC-Trigger-Coiled-Cable-Right-Angle-18-40in-Og-16005914-00

Optional - Trigger Cable

Add for 38.00 $ – 44.00 $ excl. VAT each

Untitled00086402_1

Optional - Power Cable

Add for 60.00 $ – 68.00 $ excl. VAT each

SC Top Interface Plate-Universal-Og-00

SC Top Interface Plate - Universal

Mounting Adapters

Canon C80

1

SC-DTP-S_right

SC Dovetail Plate 140

In stock ・

2

15mm mount_1

SC 15mm Rod Mount Interface

In stock ・

1

handgrip_pro_01

Top Handle Pro

In stock ・

1

Side-Mounting-Cheese-Plate-Universal-Standard-Og-16006532_04

Side Mounting Cheese Plate - Universal

Version

Rosette

1

SC Bottom Interface Plate-Universal-Og-00

SC Bottom Interface Plate - Universal

Mounting Adapters

C400 / C300 III / C500 II / C80 / C70

1

SC-15mm-Bridge-Interface-Plate_01

SC 15mm Interface Bridge Plate

In stock ・

1

UG-BP-19_left

Optional - 19mm Bridge Plate

Add for 398.00 $ excl. VAT

1

UG_BP_L_left

Optional - Bridge Plate Lite

Add for 248.00 $ excl. VAT

1

Available on backorder

Add to wishlist

SKU: 58006327 Categories: Sets, SWISS cage Tags: C80, C80 Sets, Canon, Canon Sets

Description
Additional information

The SWISS cage Universe respects Industry Norms, allowing the most advanced and complex set-ups like no other camera support system. Switching and sharing vital components between camera systems is hassle free, making time consuming reconfiguration of set-ups a thing of the past.

SC Canon C80 – Base Set contains all recommended accessories for professional rigging – optional Power distribution.

Optional - Micro Power Plate

Package Content	1x Micro Power Plate with selected DC Connector and Mounting Option
Tech. Specifications	7075 Aluminum / Black anodizing – Micro Power Plate with Dumb V-Mount Size: 100x70x30mm Weight: 240g
Battery Mount	Micro V-Mount, Micro Gold-Mount
DC Connector	Canon C80, C70
Mounting Option	15mm Mount

Optional - Power Box Pro Micro

Package Content	1x Power Box Pro Micro with selected DC Connector and Mounting Option
Tech. Specifications	7075 Aluminum / Black anodizing – Power Box Pro Micro with Dumb V-Mount Size: 103x88x51mm Weight: 396g
Battery Mount	Micro V-Mount, Micro Gold-Mount
DC Connector	Canon C80, C70
Mounting Option	15mm Mount

Optional - Power Cable

Connectors, Length	2pin OB to 2pin OB, 12", 2pin OB to 2pin OB, 18", D-Tap to 2pin OB, 12", D-Tap to 2pin OB, 18"

SC Top Interface Plate - Universal

Package Content	1x Top Interface Plate 4x ¼" Secure Mounting Screws 2x ¼" Sunk Head Mounting Screws 1x M3 Allen Wrench 1x 3/16" Allen Wrench 1x Thumb-Screw
Tech. Specifications	10x ARRI accessory mounts (with 30° steps) ARRI standard dovetail clamp 9x ¼" Threads 10x ⅜" Threads 6x ¼" Mounting Screws 1x Focus Hook mounting threads (M4) 7075 Aluminum / Black hard anodizing – Size: 105x130x 20mm Weight: 220g

SC Dovetail Plate 140

Package Content	1x SC Dovetail Plate 140
Tech. Specifications	7075 Aluminum / Black hard anodizing – Size: 140x68x10mm Weight: 116g

SC 15mm Rod Mount Interface

Package Content	1x SC 15mm Rod Mount Interface 2x Adjustable Thumbscrew 2x ¼" Mounting Screws
Tech. Specifications	7075 Aluminum / Black hard anodizing – Size: 104x38x25mm Weight: 110g

Top Handle Pro

Package Content	1x Bar Top Handle Pro 1x Bracket Top Handle Pro 2x ¼" Mounting Screws 1x M3 Allen Wrench
Tech. Specifications	7075 Aluminum / Black hard anodizing – Size: 150x48x65mm Weight: 200g

Side Mounting Cheese Plate - Universal

Package Content	1x Side Mounting Cheese Plate 2x 3/8" Screws
Tech. Specifications	7075 Aluminum / Black anodizing – Size: xx mm Weight: g
Version	Rosette

SC Bottom Interface Plate - Universal

Package Content	1x Bottom Plate 4x ¼" Secure Mounting Screws 1x M3 Allen Wrench 1x 3/16" Allen Wrench 1x Thumb-Screw
Tech. Specifications	10x ARRI accessory mounts (with 30° mounting steps) -3 sides ARRI standard dovetail clamp 7x ¼" Threads 10x ⅜" Threads 4x ¼" Mounting Screws 1x Focus Hook mounting threads (M4) 7075 Aluminum / Black hard anodizing – Size: 126x130x 20mm Weight: 250g

SC 15mm Interface Bridge Plate

Package Content	1x SC 15mm Interface Bridge Plate 5x Thumb-Screw 1x M4 Screw
Tech. Specifications	7075 Aluminum / Black hard anodizing – Size: 130x98x 34mm Weight: 335g

Optional - 19mm Bridge Plate

Package Content	1x 19mm Bridge Plate 2x 3/8" Camera screws
Tech. Specifications	7075 Aluminum / Black hard anodizing – Size: 157x125x33mm Weight: 435g

Optional - Bridge Plate Lite

Package Content	1x Bridge Plate Lite 2x 3/8" Camera screws 2x M4 Screws
Tech. Specifications	7075 Aluminum / Black hard anodizing – Size: 108x107x 18mm Weight: 225g
